ELECTROCHEMICAL DEVICES TESTING LAB

IMDEA ENERGY INSTITUTE

DESCRIPCIÓN Y FINES DE LA ENTIDAD

Electrochemical Devices Testing Lab (EDTL) offers electrochemical devices
characterization services and ageing evaluation.
The facility allows testing under specific profiles simulating power electrical
requirements for batteries and supercapacitors in stationary applications
coupled to renewable energy sources and for electric vehicles.
The EDTLab has a flexible configuration that allows testing single cells,
modules and small battery packs.

ÁREAS DE ACTIVIDAD
t Research in Batteries and Supercapacitors t Design of demand profiles
t Energy Storage Devices Testing t Acquisition and evaluation of real time data

t Characterization and ageing Analysis t Ageing Mechanism Analysis
t Development of Control Algorithms

EQUIPOS, INSTALACIONES, TIPOS DE PRUEBA Y/O 53*"-4
TECHNICAL SPECIFICATIONS:
* High Power Test System:
ā 3 modular 8 kW in charge and 12 kW in discharge DC power test channels (max 120 V / 200 A).
ā Parallel configuration to achieve 36 kW in charge and 24 kW in discharge.
ā Advanced control and measurement (Fast voltage, current, and mode transitions).
* Low Power Test System:
ā 3 modular 800 W in charge and 300 W in discharge DC power test channels (max 18 V / 50 A).
ā Master/Slave parallel and series operation up to 2,4 kW in charge and 0,9 kW in discharge.
* Climatic Chamber:
ā Wide temperature and humidity range (-40 to 180 ºC, 10 to 98% HR).
ā Fast cooling and heating rate (-3,5 and +5 ºC/min respectively).
* Data acquisition & control:
ā Several input/output modules (analogue + digital).
ā Development of LabVIEW® applications.
TESTING:
* Performance and life cycle test, fast charge / discharge steps, capacity fade, and high current peaks evaluation.
* Testing of batteries for consumption management of electric power and for electromobility.
* Development of control algorithms and waveform signals to create realistic charge/ discharge profiles:
ā Constant current, voltage, power and resistance operating modes. Frequency response analysis.
ā Control and monitoring of environmental conditions (temperature and humidity).

DIRECCIÓN PERSONA DE CONTACTO
Ave. Ramón de la Sagra, 3 Mostoles Technological Park Ignacio Almonacid
28935 Mostoles, Madrid (Spain) Specialist Technician
Tel.: +34 91 737 11 20 Fax +34 91 737 11 40 Tel.: +34 91 737 11 20 (Ext 235)
www.energia.imdea.org Email: ignacio.almonacid@imdea.org
