GSM-R LAB

ADMINISTRADOR DE INFR. FERROVIARIAS (ADIF)

DESCRIPTION AND GOALS OF THE ORGANISATION

The system consists of a post-processing unit, a response unit connected
to the MSC of the Adif GSM-R network and an onboard system at Lab Train
for voice and data generation.

AREAS OF ACTIVITY
t A platform to measure coverage, quality of service and ERTMS Level 2 projects.
interferences for Adif GSM-R and commercial GSM t A test facility for RBC-Train communications.
networks.

t A GSM-R platform for the development and validation of

TEST FACILITIES, EQUIPMENT, TYPES OF TESTING AND/OR 53*"-4

Currently all the equipment is installed in different locations:

In the Railway Technology Centre System Data Analysis is composed of:

- Analysis Tool (Net Analyzer).

At Central switching center (MSC) in Atocha:

- Responder unit.

In the Lab Train of auscultation High Speed Lines where it is installed:

- SW analysis and configuration (NetProbe) tool.
- Certification system GSM-R and Interface odometry / GPS, with the following requirements:

- Scanner Rhode & Schwarz TSM-L model with ability to scan 20 simultaneous GSM-R channels.
- 2 terminals Radio Cab-8W power.
- 4 Terminals Radio Cab-8W power.
- 1 Terminal TackMotion + GPS.

ADDRESS CONTACT PERSON
Centro de Tecnologías Ferroviarias Carlos Muñoz Ormad
Severo Ochoa St. 9 Email: cmormad@adif.es
Parque Tecnológico de Andalucía
29590 Campanillas, Málaga (Spain)
