NOISE, VIBRATION & HARSHNESS

CIDAUT FOUNDATION

DESCRIPTION AND GOALS OF THE ORGANISATION

CIDAUT Foundation is a private nonprofit institution committed to
strengthening the industrial base in the transport and energy sectors
through specific research and development programs. This center, with
about 250 researchers and technicians, has extensive experience in project
management at regional, national and European level, as has been the
leader of more than 300 research projects since 1993, when it was created.
The Cidaut Foundation has a methodology that allows complete product
development from conception of a new idea, through selection and analysis
of materials, simulation activities, material processing, prototyping and
pre-tasks industrialization to final product validation.

AREAS OF ACTIVITY
t Vibratory comfort for rolling stock t Noise maps for infraestructure
t Interior noise for rolling stock t Solution design for Noise and Vibration reduction

t Exterior noise for rolling stock t Ballast lifting
t Vibration analysis of infrastructures ( track, ...)

TEST FACILITIES, EQUIPMENT, TYPES OF TESTING AND/OR 53*"-4

Equipment:
Semianechoic Chamber & Roller Bench: Size:10 x 7.4 x 4.9 m (362 m3).
• Roller Bench (Zölner).
Acquisition & Analysis.
• LMS Siemens Scadas mobile 24 chanels. • LMS Pimento 20 chanels.
• Registration & Analysis Software (LMS-Test Lab).
Sound Quality
• Binaural Recorder with Artificial Head (HEAD ACOUSTICS). • Acoustic Quality Analyzer Software (ARTEMIS).
Squeak & Rattle Analysis.
Test: Squeak, Stick-Slip, Rattle …
• Tribotester: Wear and friction measurement of a pair of materials. • Rattle Device: rattle measurement of a pair of materials.
Durability - Squeak & Rattle Analysis.
• V850 Vibration Test System: Durability & Climatic test in three axis. Squeak and Rattle test.
Modal Analysis Test
• Vibrometer Laser Doppler (Non contact acceleration test. 200 m testing. 0-300 kHz test range). • Dynamic Shaker.
Vibroacoustic Component Behaviour.
• Petite Cabine: Insertion Loss measurement of components. • Alpha Cabin: Random Absorption measurement of components.
• Kundt Tube: Normal Absorption measurement of materials.
• Small Reverberant Chamber Acoustic Isolation measurement of components.

Tests available:
* Acoustic absorption (a), Insertion loss (IL), Transmission loss (STL) Insulation (R)
* Sound power level (Pw), Sound intensity & pressure maps, Sound sources location.
* Panel Acoustic Impedance. BIOT parameters. * Ballast lifting.
* Modal Analysis. * Pass by.
* RASTI Measurement. * Noise maps.

ADDRESS CONTACT PERSON
Parque Tecnológico de Boecillo - Parcela 209 Miguel Ángel Morcillo López
47151 Boecillo, Valladolid Responsable de Negocio. Ferrocarril
Tel.: +34 983 54 80 35 Tel.:+34 607 36 99 75
www.cidaut.es Email: migmor@cidaut.es
