ELECTRICAL EQUIPMENT LAB

TECNALIA

DESCRIPTION AND GOALS OF THE ORGANISATION
Laboratory of international reference, focused on the support to the
development and conformity assessment of electrical products for T&D
networks and Smart Grids, as well as industrial applications.
We support our clients, mostly manufacturers of electrical equipment and
electrical utilities, with our technical human expertise and singular testing
facilities to assess the compliance with the product standards and technical
specifications; key for the design of the product and its access to the
market.
We serve as a third-party laboratory, accredited by ILAC ENAC and
recognized by the main electrical utilities in the world.

AREAS OF ACTIVITY
t Conformity assessment with product standards t On-SiteTests:Commissioning, Diagnostics
t Conformity assessment with technical specifications t Qualification of suppliers and Technical consulting

t Compliance with the EMC Directive and CE Marking t Product Inspection & Market surveillance
t Certification of Smart Meters t R&D project with high TRL

TEST FACILITIES, EQUIPMENT, TYPES OF TESTING AND/OR 53*"-4
Laboratory Tests:
* POWER Laboratory for Short-circuit, short time and peak withstand currents, making and braking, internal arc tests,
etc: 300 MVA, 1 second; 150 kA up to 1000 V; decreasing currents for voltages from 2,8 to 38 kV.
* HIGH VOLTAGE Laboratory for dielectric tests: withstand and applied voltage, dielectric strength, partial discharges,
etc: 550 kV at power frequency; 1.800 kV for lightning impulse.
* LOW VOLTAGE Laboratory for temperature-rise tests, degree of protection, etc: up to 12.000 A for temperature-rise
tests; large climatic chamber: 5,5 x 4 x 4 m.
* POWER ELECTRONICS Laboratory for the conformity assessment of inverters and converters: islanding, voltage
sags, safety tests, etc.
* EMC Laboratory for radiated and conducted emission and immunity.
* RELIABILITY tests by means of HALT technology (Highly Accelerated Life Testing) with the aim of detecting failure
modes on electric/electronic components.
* ENVIRONMENTAL testing on electric components such as vibration, shock, temperature, humidity, etc.
* SMART METERS Laboratory for the certification of the Smart Meters and Data Concentrators: PRIME and DLMS
Protocols, MID Directive, CENELEC tests.

Products tested: Distribution Transformers, Instrument Transformers, LV Switchboards, MV Switchgear, MV & HV
Cables, Fuse holders and fuse links, PV Inverters, Smart Meters & Concentrators, Relays, etc.

On-Site Tests:
*Mobile laboratories including a Resonant Test Unit for HV cables and testing equipment for the diagnosis of large
rotating machines at power and industrial plants and predictive maintenance of power transformers at substations.
