RIDE DYNAMICS/INSTRUM.WHEELSETS

CETEST

DESCRIPTION AND GOALS OF THE ORGANISATION

Static testing of vehicles (using portable test benches) and dynamic
on-track running tests on real operating conditions for vehicle ride dynamics
verification and validation.

CETEST also provides tailored made system (Instrumented Wheelsets) for
wheel-rail contact forces measurement to train manufacturers, train
operators and infrastructure managers.

AREAS OF ACTIVITY

t Safety against derailment / wheel equalization t Vehicle weighting
t Bogie rotational resistance (X-factor) t Ride quality

t Suspension flexibility (souplesse) / lean testing t yaw movement
t Centre of gravity t Wheel / rail contact forces

TEST FACILITIES, EQUIPMENT, TYPES OF TESTING AND/OR TRI"LS

STATIC CHARACTERIZATION
* Verification and validation testing according to main international standards: EN 14363, UIC 518, US CFR 49, etc.
* 3 sets of portable fully autonomous test benches for shipping to customer´s premises for local testing avoiding costs
(freight, time) of vehicle shipment.
* Instrumentation: inclinometers, displacement sensors, load cells.

DYNAMIC ON-TRACK MEASUREMENTS
* Verification and validation testing according to main international standards: EN 14363, UIC 518, US CFR 49, ISO
2631, ENV 12299, etc.
* Instrumentation: accelerometers, displacement sensors, strain gauges, gyroscopes, wheel/rail forces (see below for
more information), other special sensoring systems.

INSTRUMENTED WHEELSETS: www.cetestgroup.com/iws
A sensing system able to measure, in an uncoupled manner, the contact forces associated to the wheel / rail interaction.
Tailored made extensometric instrumentation, advanced communication and acquisition and complex post processing
algorithms offering unique performance and accuracy. Main technical characteristics:
- Adaptable to any wheel and axle configuration and geometry.
- Adaptable communication solutions with the wheelset (inc. optical telemetry system without batteries for drilled axles)
- Calibration and verification made in both static and rolling conditions.
- Patented methodology, tested in all market segments (metro, freight, high speed, locomotives...).
Most of the customers are train manufacturers using this system for new vehicle homologation. However, operators and
infrastructure managers also use these Instrumented WheelSets for advanced track measurement which can allow for
optimization of track maintenance.

ADDRESS CONTACT PERSON
C/ Lazkaibar, s/n Eva Martínez
20200 Beasain Sales and Marketing Director
Tel.: + 34 943 02 86 90 Tel.: +34 943 02 86 90
www.cetestgroup.com Email: emartinez@cetestgroup.com
