GEOTECHNICAL LABORATORY

GEOLOGICAL AND GEOTECHNICAL DEPARTMENT

POLYTECHNIC UNIVERSITY OF VALENCIA

DESCRIPTION AND GOALS OF THE ORGANISATION

The Geotechnical Laboratory has a very long legacy in field and laboratory
geotechnical testing. It is specialized in studies and laboratory and field
testing in the sphere of Soil and Rock Mechanics. It provides technical
assistance to both private and public entities which develop activities
related to geotechnical engineering.
It cooperates in research projects with public and private companies in
order to develop new materials that can be used in railways embankments,
including the reuse of waste from the construction and transport sectors.

AREAS OF ACTIVITY
t Soils and unbound aggregates characterization test t Non-destructive test (NDT)
t Triaxial test for soils and rocks t Measurement and analysis of railway track vibration

t Consolidation test: Oedometer and Rowe cell t Durability, abrasivity and drillability test
t Elastic parameters for soils and rocks t Dynamic plate loading test for 300 mm

TEST FACILITIES, EQUIPMENT, TYPES OF TESTING AND/OR 53*"-4

* Full equipment for the characterisation of soils and unbound aggregates: 200 and 300 mm diameter sieves.
* Oedometric deformation equipment: 10 oedometric devices and 2 Rowe cells (75 and 250 mm diameter).
* Full equipment for soil triaxial tests: adapted for triaxial tests on soil specimens with 38 and 50 mm diameter and
unbound aggregate specimens (subballast) with 100 mm diameter.
* Light Falling Weight Deflectometer (LFWD) for measuring compressibility modulus in soils and unbound aggregates.
* Triaxial permeability equipment and cells adapted to PF-7 Annex 3.
* Direct Shear test equipment for 100x100 mm specimens.
* 150 tonnes Hydraulic press with sensors to measure Young modulus and Poisson coefficients (by means of
extensometric gauges).
* Full Rock Triaxial equipment capable of measuring resistance and permeability parameters.
* Hoek Shear Box for measuring discontinuity resistance.
* Tilt Test Equipment.
* Full P&S Wave Ultrasound equipment. Frequencies 24, 54, 100, 150, 250 and 500 Hz.
* Hardness and abrasivity Cerchar equipment.
* Drilling Ratio Index (DRI) equipment.
* Slake Durability equipment.
* Franklin Point Load equipment.
* Full equipment to obtain rock specimens: diamond cutting devices, polisher, etc.
* Full equipment for railway track vibration measurement and analysis: Datalogger, acelerometers, software for
postprocessing.

ADDRESS CONTACT PERSON
Universidad Politécnica de Valencia Carlos Hidalgo Signes
Geological and Geotechnical Department Technical Laboratory
Edificio 4I-planta baja Tel.: +34 96 387 75 83
Camino de Vera, s/n 46022 Valencia (Spain) Email: chidalgo@trr.upv.es
